Ezviz H90 Dual 4MP 2K⁺ & 2K⁺ Dual-Lens Pan & Tilt Wi-Fi Camera
Specifications
Model CS-H90-R100-8H44WKFL
Camera
Image Sensor 1/3″ Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens Top Lens: 2.8mm @ F1.6, Field of view : Diagonal 110°, Horizontal 96°, Vertical 54°
Bottom Lens: 6mm @ F1.6, Field of view : Diagonal 60°, Horizontal 52°, Vertical 28°
PT Angle Pan: 324°, Tilt: 90°
Minimum Illumination 0.5 Lux @(F1.6, AGC ON),
0 Lux with IR (*data is obtained from EZVIZ laboratories)
Lens Mount M12
Day & Night IR-cut filter with auto switch
DNR 3D DNR
WDR Digital WDR
Black & White Night 30 m (98 ft)
Video & Audio
Max Resolution 2K+ (2880 × 1620)
Frame Rate Max:15fps; Self-Adaptive during network transmission
Video Compression H.265 / H.264
H.265 Type Main Profile
Video Bit Rate Ultra-HD; Hi-Def; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz
Security WPA-PSK/WPA2-PSK
Transmission Rate 11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps
Wi-Fi Pairing AP paring
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Wired Network RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
Functions
Smart Alarm AI-powered human shape detection
AI-powered vehicle shape detection
Motion detection
Auto Tracking Supports
Customized Alert Area Supports
Two-way Talk Supports
Preset Locations Supports
General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
Storage
Local Storage Supports microSD card (max. 512 GB)
Cloud Storage Supports EZVIZ CloudPlay storage (subscription required)
General
Operating Conditions -30°C to 50°C ( -22 °F to 122 °F )
Humidity 95% or less (non-condensing)
IP Grade Weatherproof Design
Power Supply IP65 + 2h rainstorm
Power Consumption MAX. 18W
Dimensions 224 × 135 × 136 mm (8.82 × 5.31 × 5.35 inch)
Packaging Dimensions 255 × 176 × 194 mm (10.04 × 6.93 × 7.64 inch)
Weight Net weight: 723 g (25.51 oz)
With Package: 1203 g (42.43 oz)
In the box
In the box – H90 Dual 2K+ Camera
– Power Adapter
– Drill Template
– Waterproof Kit
– Screw Kit
– Regulatory Information × 2
– Quick Start Guide
